Coherent® high-performance OBIS™ LX/LS laser systems are compact and feature a plug-and-play laser platform that enables a wide range of wavelengths, from the UV to near-infrared ranges, to be realized on a single platform. Even though each laser utilizes two technologies, Coherent's patented Optically Pumped Semiconductor Laser (OPSL) or diode-based lasers, the OBIS LX/LS laser system has the same set of beam parameters, allowing the user to change wavelengths as needed with the plug-and-play laser platform. Each laser includes USB, RS-485 and full-featured I/O interfaces. A multi-color LED has been integrated into the top cover to visualize laser status.
NOTE: For operation, a power supply is required, which is sold separately.The CDRH certified system requires an OBIS remote control. The use of an OBIS heat sink is recommended.
Product Specification
| OBIS Series Name | Wavelength (nm) | Key Features | Beam Characteristics | typical application |
| line width | ||||
| OBIS LX SF single frequency Narrow line width new! Version with pigtail fiber. |
405, 633, 660, 785 | High beam quality
Power up to 50 mW |
< 0.3 pm (405 nm and 633 nm)
< 1.5 pm (660 nm) < 0.7 pm (785 nm) |
Raman Spectroscopy
interferometry HeNe (helium-neon) holographic optics Medical imaging and instrumentation Metrological measurements Semiconductor monitoring Particle characterization Gas Detection |
Product Specification
| OBIS Series Name | Wavelength (nm) | Key Features | Beam Characteristics | typical application | |
| Beam quality | modem | ||||
| OBIS LS | 488, 505, 514, 532, 552, 561, 594 | Excellent beam quality
Power up to 200 mW |
M² ≤ 1.1 | 50 KHz (digital)
100 KHz (analog) |
flow cytometry
Microscopy and imaging DNA sequencing optogenetics spectral analysis Drug screening semiconductor manufacturing |
| OBIS LX | 375, 405, 413, 422, 445, 458, 473, 488, 505, 514, 522, 633, 637, 640, 647, 660, 685, 690, 730, 750, 785, 808, 980 | High beam quality
Power up to 365 mW |
M² ≤ 1.2 | 150 MHz (digital)
500 KHz (analog) |
|
| OBIS LS FP pigtail |
488, 514, 532, 552, 561, 594 | Singlemode conformal fiber with FC/APC connectors
Power up to 150 mW |
M² ≤ 1.1
Fiber with FC/APC |
50 KHz (digital)
100 KHz (analog) |
|
| OBIS LX FP pigtail |
375, 405, 413, 445, 458, 473, 488, 505, 514, 522, 633, 637, 640, 647, 660, 685, 690, 730, 785 | Singlemode conformal fiber with FC/APC connectors
Power up to 200 mW |
M² ≤ 1.1
Fiber with FC/APC |
150 MHz (digital)
500 KHz (analog) |
|
| OBIS Lasers for Galaxy Combiner, Pigtails | 405, 445, 458, 473, 488, 514, 532, 552, 561, 594, 640 | Single-mode, bias-preserving fiber with FC/PC connectors for ultra-flat polishing
Power up to 200 mW |
M² ≤ 1.1
Fiber Optics with FC/PC (FC/UFC) |
LX and LS see above | Microscopy and imaging
optogenetics |
